Karcher B 220 R Bp

SKU B-220-R-Bp Category
Karcher B 220 R Bp
Karcher B 220 R Bp - Image 2
Karcher B 220 R Bp - Image 3
Karcher B 220 R Bp - Image 4
Karcher B 220 R Bp - Image 5
Karcher B 220 R Bp - Image 6
Karcher B 220 R Bp - Image 7
  • Cylindrical or Disc Scrub Deck
  • 46″ Suction Bar
  • 33-43″ Cleaning Path
  • Single dial to select mode of operation
  • LCD display to easily check operational status at a glance
  • 50% less residual moisture on industrial floors
  • Daytime running lights ensure a safer cleaning experience

Models shown may include optional features.

Karcher

Starting at:

$30,802.00

Call to Order

Call to Order

This product ships via LTL Freight. See our Shipping Policy for details.

Exceptional performanc for industrial cleaning.

The B 220 R Bp ride-on scrubber is specifically engineered to meet the heavy-duty requirements of the industrial and manufacturing sectors, where efficiency and reliability are paramount. By combining a wide 34-inch working path with advanced cleaning technology, this machine enables you to maintain a pristine facility while significantly reducing the time required for floor maintenance. This solution-oriented approach ensures that your team can focus on their core tasks, confident that their environment is being maintained to the highest standards of cleanliness and safety. Whether you are tackling large production floors or warehouse aisles, this scrubber provides a powerful way to protect your assets and enhance operational productivity.

KIK System Easy Operation Configurable USGBC Leed Rating

Specifications

Technical Specifications  B 220 R BP R85
+ 2 Side Brooms		 B 220 R BP R85 B 220 R BP D90 B 220 R BP D110
Brush cleaning path / width Inch 34 34 35 43
Brush type Cylindrical Cylindrical Disc Disc
Brush quantity Units 2 2 2 2
Brush diameter Inch 3.5 33 35 43
Suction bar (squeegee) width Inch 46 46 46 46
Drive Traction Traction Traction Traction
Solution / recovery capacity Gal 58/58 53 / 53 53 / 53 53 / 53
Practical productivity Sq Ft/ Hr 64,045 64,045 64,045 64,045
Operating noise level dBA 67 67 67 67
Battery charger On board On board On board On board
Brush contact pressure Lbs 207 207 207 207
Brush speed RPM 1300 180-1300 180-1300 180-1300
Drive / vac motor rating Watts 600 2500 2500 2500
Climbing ability – maximum slope % Grade 10 10 10 10
Max working speed MPH 6 6 6 6
Minimum turning radius Ft 2.9 2.9 2.9 2.9
Weight with batteries Lbs 2,191 2,191 2,191 2,191
Dimensions (LxWxH) Inch 75 x 36 x 56 75 x 42 x 56 75 x 42 x 56 75 x 42 x 56

Models

Part No. Description
9.200-051.0 B 220 R Bp 2SB R 85, cylindrical scrub deck (batteries not included)
9.200-052.0 B 220 R Bp D 90, disc scrub decl (batteries not included)
9.200-053.0 B 220 R Bp R 85, cylindrical scrub deck, 36V / 360 Ah batteries
9.200-054.0 B 220 R Bp R 85, cylindrical scrub deck, 36V / 312 Ah AGM batteries
9.200-055.0 B 220 R Bp 2SB R 85, cylindrical scrub deck, 36V / 360 Ah WET batteries
9.200-056.0 B 220 R Bp 2SB R 85, cylindrical scrub deck, 36V / 312 Ah AGM batteries
9.200-057.0 B 220 R Bp D 90, disc scrub deck, 36V / 312 Ah AGM batteries
1.246-283.0 B 220 R Bp 2SB R 85, cylindrical scrub deck, Lithium-ion batteries + Dose & Beac
1.246-275.0 B 220 R Bp 2SB R 85, cylindrical scrub deck, 36V / 360 Ah WET batteries + Dose

Accessories

Part No. Description
4.778-009.0 46″ parabolic suction bar ■
4.039-362.0 46″ suction lip set, Linatex ■
5.035-344.0 KIK key yellow, operator ■
5.035-348.0 KIK key grey, foreman ■
2.644-099.0 KEM machine connect ■
4.039-363.0 Suction blade set, 46″ polyurethane □
4.037-166.0 Side strips □
4.037-167.0 Side strips, oil resistant □
6.438-010.0 Wheel with ball bearing D350 Elasthane □
6.435-810.0 Front tire, traction, blue, oil-proof □
2.644-088.0 Add-on kit, side scrubbing deck B150R □
2.644-276.0 Add-on kit, side scrubbing deck B220R □
2.763-031.0 Add-on kit, stiffening brush head D90 □
4.035-076.0 KIK key, white □
4.035-408.0 Set, KIK key, yellow □
4.035-064.0 Set, KIK key, white □
6.680-124.0 Hose fresh water complete □
4.444-015.0 Suction hose accessories □
2.642-058.0 Add-on kit, spray sucking B150R □
4.070-006.0 Tank cleaning agents complete □
4.039-355.0 RM tank complete, 5L* □
4.035-513.0 Cover tank flushing system complete □
2.641-244.0 Add-on kit water refilling tank □
2.641-243.0 Add-on kit water refilling tank with wall mount □
2.641-811.0 Cleaning agent dosing system DS 3 □
5.035-488.0 Home Base kit (adapter and cable hook) □
6.980-077.0 Home Base double hook (requires 5.035-488.0) □
4.070-075.0 Home Base universal hook kit (requires 5.035-488.0) □
6.980-078.0 Home Base mop clip (requires 5.035-488.0) □
6.980-080.0 Home Base bottle hook (requires 5.035-488.0) □
4.035-406.0 Set, Home Base box □
4.035-516.0 360° warning beacon □
2.644-225.0 Add-on kit deflector roll stackable □
4.035-512.0 Cover complete □
2.644-089.0 Add-on kit overhead guard □
2.644-391.0 Add-on kit equipment management plug-in □

*Only suitable for compatible scrubber dryers with Dose cleaning agent system

■ Included  □ Optional

Literature

Karcher B 220 R Bp Product Sheet Product Sheet – Karcher B 220 R Bp
