Models shown may include optional features
Call to Order
Outstanding suction performance.
The brand-new B 110 R is perfect for all floors. The robust front bumper prevents damage to the machine and other objects, while speed dependent water supply saves on water and detergents. The newly designed squeegee picks up more water and requires less attention, and the adjustable seat allows workers to feel more comfortable during long shifts.
| Technical Specifications | ||
| Cleaning path / width | Inch | 30 |
| Brush type | Clyindrical or Disc | |
| Brush quantity | Units | 2 |
| Brush diameter | Inch | 4″ cylindrical, 15″ disc |
| Suction bar (squeegee) width | Inch | 37 |
| Drive | Traction | |
| Solution / recovery capacity | Gal | 29 / 29 |
| Theoretical / practical productivity | Sq Ft/ Hr | 48,440 / 31,485 |
| Operating noise level | dBA | 59-74 |
| Battery charger | Shelf | |
| Brush contact pressure | Lbs | 165 |
| Brush speed | RPM | 180 – 1200 |
| Drive / vac motor rating | Watts | 600 |
| Vac motor suction | cfm | 53 |
| Waterlift | In of Water | 68 |
| Weight without batteries | Lbs | 1190 |
| Dimensions (LxWxH) | Inch | 65 x 30 x 52 |
| Minimum turning radius | Feet | 2.87 |
| Climbing ability – maximum slope | % Grade | 10 |
| Max working speed working | MPH | 3.8 |
| Part No. | Description |
| 9.841-441.0 | BD 75/110 R Bp, Wet battery, 30″ disc scrub deck |
| 9.841-444.0 | BD 75/110 R Bp, AGM battery, 30″ disc scrub deck |
| 9.841-445.0 | BD 75/110 R Bp, Wet battery, 30″ cylindrical scrub deck |
| 9.841-449.0 | BD 75/110 R Bp, AGM battery, 30″ cylindrical scrub deck |
| Part No. | Description | |
| 4.778-007.0 | 950 mm parabolic squeegee | ■ |
| 2.763-005.0 | D 75 scrub deck* | ■ |
| 2.763-047.0 | R 75 scrub deck* | ■ |
| 4.039-366.0 | Linatex squeegee blade set | ■ |
| 4.035-605.0 | Red brush (for R 75 scrub deck) | ■ |
| 6.907-731.0 | Green brush (for R 75 scrub deck) | ■ |
| 6.907-732.0 | Balck brush (for R 75 scrub deck) | □ |
| 6.907-730.0 | Orange brush (for R 75 scrub deck) | □ |
| 6.907-729.0 | White brush (for R 75 scrub deck) | □ |
| 4.039-357.0 | Polyurethane replacement squeegee blade | □ |
| 2.644-231.0 | Spray suction kit | □ |
| 4.039-350.0 | Warning beacon kit | □ |
| 4.039-327.0 | Lid with tank rinsing | □ |
| 2.644-245.0 | Dose system | □ |
| 4.035-406.0 | Home Base box | □ |
| 4.039-349.0 | Mop Home Base attachment kit | □ |
| 8.622-835.0 | Trojan T105 225 Ah battery | □ |
| 8.632-254.0 | Discover EVG76A-A 255 Ah battery | □ |
| 8.644-222.0 | Shelf charger for wet batteries | □ |
| 8.643.374.0 | Shelf charger for AGM batteries | □ |
| 8.644-917.0 | Right side scrub deck | ◆ |
*Depending on model selected
■ Included □ Optional
◆ Optional, must be installed at the factory.
 |
Product Sheet – Karcher B 75/110 R Bp |
